16Ch 4TB HDD IP NVR Video Surveillance System with 12x 4MP Bullet Camera and 4x 4MP Turret Cameras J535441
16Ch 4TB HDD IP NVR Video Surveillance System with 12x 4MP Bullet Camera and 4x 4MP Turret Cameras J535441
What’s Included - 16 Ch. 4K IP NVR with built-in 16 RJ45 PoE Ports, 4 TB pre-installed HDD, 4 MP Fixed lens Bullet Camera with built-in Microphone (12). 4 MP Motorized Varifocal Turret Cameras with built-in Microphone (4). 100’ Cat5e Cable (16) 1-ch HDMI, 1ch VGA. HDMI at up to 4K(3840x2160) resolution
Key Features - 100’ Night vision (Bullet Cameras), 175’ft Night Vision (Turret Cameras), 4K HDMI Output (easy to connect to a 4K monitor or TV), H. 265 compression, smart alerts via alarms and email notification, supports easy firmware upgrade via cloud (Recorder & Cameras), Corridor view mode – perfect for hallways, doors, windows.
Remote Monitoring - with Revo Ultra “mobile App” and “browser login”, you can view live feed, review past footage, get notifications instantly, can adjust settings, Set alarms, check motion events, view multiple units at once and more.
DIY Installation - We provide the necessary material such as videos and manual so that you can install the system yourself. All you have to do is just follow some simple steps and you’re done.
US based Support & Warranty - We provide 2-year free warranty which includes parts replacement for free and Lifetime technical support (email reply within 24 hours). You can also call us at: +1(866) 625-7386 (Mon: 8am-6pm cst, tue-fri: 8am-5pm cst).
With incredible video quality, ease of use, and powerful networking tools, Revo Ultra is the very best that Revo has to offer. Enjoy additional professional and premium-residential features with Revo Ultra Plus. The Revo Ultra's superb video quality is based on IP technology. The “RUP161BNDL-17” is a complete plug and play HD surveillance system with 16 CH Professional Grade NVR, 4TB & 16x 4MP HD Indoor/outdoor Motorized Audio Capable Turret Cameras. Revo Ultra Plus NVRs feature state of the art 4K Video Output, H.265 Compression, support up to 12MP Cameras and up to an astounding 32TB of Hard Drive Capacity (4TB Pre-installed). The Cameras feature IR anti reflection glass, professional grade “OSRAM” LEDs, massive 2K Sensors, double the resolution of standard 1080p. The “OSRAM” LEDs strongly illuminate the scene up to an unprecedented 100’ in total darkness. All 8 cameras come equipped with a built-in microphone for audio streaming and recording. The cameras are built for the outdoors capable of handling temperatures as hot as 140F and as cold as -40F. The “RUCB36-1A” bullet camera features a 3.6mm fixed lens for wide field of view coverage. The “RUCT2812-1” Turret Camera features 4X optical Zoom and a 2.8 to 12mm automatic lens allows convenient adjustment of the field of view of the camera. The polished look and intuitive feel of the Ultra's interface is a joy for everyday use whether you're using the NVR itself, the Mobile App, Computer Software or Browser.
| More Details | More Details | More Details | More Details | More Details | More Details | |
|---|---|---|---|---|---|---|
| NVR Channel/Pre-installed HDD | 16Ch./4TB | 16Ch./4TB | 16Ch./4TB | 16Ch./4TB | 16Ch./4TB | 16Ch. / 3TB |
| Camera Resolution | 4MP | 4MP | 4MP | 4MP | 4MP | 5MP Starlight |
| Camera Types | Bullet - 12Pcs, Turret - 4Pcs | Bullet - 8Pcs, Turret - 4Pcs | Bullet - 6Pcs, Turret - 2Pcs | Bullet - 8Pcs, Turret - 2Pcs | Turret, Bullet, Vandal Dome | Bullet (4 Pcs.) & Turret (4 Pcs.) |
| Night Vision | 100' (Bullet), 175'(Turret) | 100' (Bullet), 175'(Turret) | 100' (Bullet), 175'(Turret) | 100' (Bullet), 175'(Turret) | 100' (6 Cameras), 175'(4 Cameras) | 100' |
| Angle of View/Lens | Bullet -79°/4mm Lens, Turret - 27° to 91°/2.7 to 12mm Motorized Varifocal Lens | Bullet -79°/4mm Lens, Turret - 27° to 91°/2.7 to 12mm Motorized Varifocal Lens | Bullet -79°/4mm Lens, Turret - 27° to 91°/2.7 to 12mm Motorized Varifocal Lens | Bullet -79°/4mm Lens, Turret - 27° to 91°/2.7 to 12mm Motorized Varifocal Lens | 4 Bullet (79°/4mm Lens), Turret (78°/3.6mm), Vandal Dome (27 ° to 91°/2.8 to 12mm Lens), 2 Bullet (25° to 105°/2.8 to 12mm Lens) | Bullet - 80°/4mm Lens, Turret - 105°/2.8mm Lens |
| Compression | H.265+/H.265/H.264 | H.265+/H.265/H.264 | H.265+/H.265/H.264 | H.265+/H.265/H.264 | H.265+/H.265/H.264 | H.265/H.264 |
| Optical Zoom | 4x Zoom in Turret Cameras | 4x Zoom in Turret Cameras | 4x Zoom in Turret Cameras | 4x Zoom in Turret Cameras | 4x Optical (Motorized Varifocal Lens - 2 Dome, 2 Bullet) | NA |
| Audio | All cameras have Built-in-MIC | All cameras have Built-in-MIC | All cameras have Built-in-MIC | All cameras have Built-in-MIC | Built-in-MIC (6 cameras), Audio I/O (Motorized Varifocal Lens - 2 Dome, 2 Bullet) | All cameras have Built-in-MIC |
| Recording Resolution | up to 4K | up to 4K | up to 4K | up to 4K | up to 4K | up to 4K |
| Other Features | 4 SATA, Maximum Capacity - 40TB, Network Interface (1 RJ-45 10M/100M/1000M),USB Interface (Front panel: 2, Rear panel: 1 x USB3.0), Power Supply (100 ~ 240V AC) | 4 SATA, Maximum Capacity - 40TB, Network Interface (1 RJ-45 10M/100M/1000M),USB Interface (Front panel: 2, Rear panel: 1 x USB3.0), Power Supply (100 ~ 240V AC) | 4 SATA, Maximum Capacity - 40TB, Network Interface (1 RJ-45 10M/100M/1000M),USB Interface (Front panel: 2, Rear panel: 1 x USB3.0), Power Supply (100 ~ 240V AC) | 4 SATA, Maximum Capacity - 40TB, Network Interface (1 RJ-45 10M/100M/1000M),USB Interface (Front panel: 2, Rear panel: 1 x USB3.0), Power Supply (100 ~ 240V AC) | 4 SATA, Maximum Capacity - 40TB, Network Interface (1 RJ-45 10M/100M/1000M),USB Interface (Front panel: 2, Rear panel: 1 x USB3.0), Power Supply (100 ~ 240V AC) | 2 SATA, Maximum Capacity - 20TB, Network Interface (1 RJ-45 10M/100M/1000M),USB Interface (Front Panel-1, Rear Panel-1), Power Supply (100 ~ 240V AC) |
